DX50-01U Permanent Magnet: Quality Inspection Report

Home  ꄲ  Dexinmag News  ꄲ  Permanent Magnet  ꄲ  DX50-01U Permanent Magnet: Quality Inspection Report







1. Mechanical Dimensions
Overall dimensions:
Length * Width * Height
120 mm * 102 mm * 20 mm



2. Packing List

Item

 Specifications Quantity
Permanent magnet

DX50-01U

1
Certificate of Conformity

-

1
Test Report

-

1



3. Packaging Type
Paper packaging box



4. Packaging Filler
Foam board



5. Labeling

Product Nameplate



6. Total Equipment Weight
1.02 kg





Performance test report
 Introduction
    1. Test purpose
Through the analysis of the test results, the evaluation of the product performance is obtained;
Evaluate whether the test product meets the technical requirements;
Provide reference data for product design and after-sales service, and provide a strong basis for leaving the factory.
    2. Basic information
 Product Name:
Permanent magnet		 Product model: DX50-01U
Test time: January 12, 2026
    3. Testing environment
The detection environment is closer to the actual environmental conditions used by the user, including factors such as lead wire length and ambient temperature. The time is selected in the time interval where the fluctuation of the geomagnetic field is small. Before the test, the instruments required for the test were turned on and warmed up in advance and the measurement environment was recorded, as shown in Table 1.
Measurement environment
Environment temperature Product initial temperature Lead length Environmental magnetic field
5.0℃ 5.0℃ - 0~30000nT
Table 1 Measurement environment data

Magnetic field parameter test
    1. Using the device

DX-180 Gauss Meter
    2. Magnetic field measurement
This product uses the following measurement methods:
Fixed-point measurement: measure the magnetic field at the target point
Magnetic field strength
No. Magnetic field strength（mT）
1 133.5
Table 2 Magnetic field strength data
　
Conclusion
The magnetic field and electrical performance of the product meet the requirements of the corresponding technical parameters. The final performance of the product is subject to this document.





Customization is available, please let us know your requirements, and we will design a professional plan for you. Thank you!
